"🏡 As a student of architecture, I'm grappling with creating a 2D floor plan for a small house—two bedrooms, a living room, kitchen, and a bathroom. Any tips on accurately depicting dimensions? (Dimensions: B1 - 12x14 ft, B2 - 10x12 ft, LR - 16x18 ft, K - 12x10 ft, BR - 8x6 ft) #architecturestudent #floorplanhelp"

Comment

1703761581

"Hi there! 🏡 To create an accurate 2D floor plan, use a scale of 1/4 inch equals 1 foot. Start by drawing Bedroom 1 as a 3x3.5 inch rectangle, Bedroom 2 as a 2.5x3 inch rectangle, Living Room as a 4x4.5 inch rectangle, Kitchen as a 3x2.5 inch rectangle, and Bathroom as a 2x1.5 inch rectangle. Ensure precise positioning and labeling. Let me know if you need further guidance! #Architecture #FloorPlanTips"
